ATTRIBUTES:

• Optional Package/Box Quantity: 1
• Size: 2" Medium
• Material: Stainless steel
• seal: NBR
• Working Pressure: 1000 PSI (6.9 MPa)
• Burst Pressure: 4000 PSI (27.58 MPa)

APPLICATIONS:

>Claw couplings are most commonly used for conveying air and water, and are not to be used for steam applications.

>Common industry applications include: Underground and surface mining, mineral processing, compressor and air tool industries and hire companies

> The minsup sure-lock®  stainless steel couplings are high quality precision. Cast fittings suitable for corrosive enviroments.

NOTE:

> Constant vibration created by air drills, pavement breakers etc. is destructive to air hose couplings, especially the quick-acting type. To provide protection, connect one end of a 1 to 3 meter length of air hose to the tool using the heat-treated "No. 3500" Steel Nipple which withstands vibration for a longer period.

> Connect the other end of "Whip Hose" to the air supply with the quick-acting coupling. "Whip Hose" should remain permanently connected to the tool and should be the same diameter as the supply line hose.

CONSTRUCTION:

>316 Stainless steel CF8M

FEATURES:

>Sure-lock®  couplings are simple, reliable and provide an airtight connection.

> this style of coupling excels where speed, easy economy and saftey are paramount.

SAFTEY NOTES:

>WARNING!! Never use Sure-Lock® couplings for steam service! None of dixon's catalogue infomation is to be interpreted to mean that this type of coupling is suitable for use on steam hose

> The use of a minsup saftey locking pin is necessary to ensure that Sure-Lock®  claw couplings will not become accidentally disconnected. This ensures that the fittings are properly connected as the pin will not go through the holes in both couplings until the couplings are locked into place.
